POP Barreaudé

NOUVEAUTÉ – AVRIL 2025 – LE PORTILLON BARREAUDÉ PRÊT À POSER

Atouts produits

Polyvalent, gâche réversible pour un double sens d’ouverture (tirant ou poussant)
Portillon à sceller ou sur platine soudée
Livré prêt à poser

Caractéristiques

  • • Cadre : 40x 40 mm

    • Remplissage : tube 20 x 20 mm

    • Vide entre barreaux : 110 mm

    • Poteaux : 60 x 60 mm

    • Sens d’ouverture : livré droite poussant

    • Garde au sol : 50 m

Application(s)

  • Sites résidentiels
  • Entreprises / Collectivités

Informations complémentaires

  • Portillon prêt à poser.
  • Portillon réversible
  • Serrure avec cylindre européen
  • Acier galvanisé + plastification polyester.
  • Gonds Locinox
  • Gâche Locinox en acier inoxydable

Coloris standards

  • RAL 6005
  • RAL 7016
  • + 200 COLORIS RAL

Caractéristiques techniques

DIAMETRE

PASSAGE NOMINAL 1,00 m

PASSAGE NOMINAL 1,25 m

PASSAGE RÉEL (m)

1,00

1,16

VIDE ENTRE POTEAUX (m)

1,09

1,25

VIDE SOUS PORTILLON (m)

0,50

SECTION DES POTEAUX (mm)

60 x 60



PASSAGE NOMINAL (m)

HAUTEUR HORS SOL (m)

LONGUEUR POTEAUX (m)

1,00

1,13

1,56

1,20

1,33

1,76

1,50

1,63

2,06

1,70

1,83

2,26

1,90

2,03

2,46
